AIR/MULTIPURPOSE HOSES GLACIER MULTIPURPOSE

Glacier is a cold weather multipurpose hose specifically engineered for use in sub-zero applications while maintaining its kink-resistant flexibility and easy-reeling characteristics. Featuring an oil-resistant, synthetic rubber tube that is reinforced with a spiraled high tensile polyester yarn, Glacier provides a constant working pressure of 300 PSI and a 4:1 burst safety factor, capable of handling air, oil, gasoline, diesel, green fuels (biodiesel, biodiesel blends, ethanol, ethanol blends), kerosene, fuel oil and some chemicals. This hose comes standard with an embedded static wire.

= Make To Order (MTO)

CONSTRUCTION TUBE: ECO, ARPM - Class A Capable of Handling Diesel, Kerosene and Gasoline Low Rating to -65F, -54C COVER: ECO, ARPM - Class A Abrasion Resistant Easy to Reel Even at Extreme Cold Temperatures REINFORCEMENT: 4-Spiral Polyester Yarn Provides a Working Pressure to 300 psi More Flexible than Braid Reinforced Hose Easier to Route Assemblies Easier to Coil and Handle Less Susceptible to Premature Failure than Braided Hose if Subjected to Torque TEMPERATURE RANGE: -65F to +180F, -54C to +82C Still Flexible at Extreme Low Temperatures PACKAGING: Reels 250-700 ft. Reels Depending on I.D. MOLDED COVER PROCESS MSHA Approved Cover Blue Showroom Quality Color Dust Free RESISTANCE BRANDING: Thermoid Glacier MP Hose Size I.D. WP Made In USA COVER COLOR: Black, Blue

Abrasion Oil

*Footage between reels may vary. Maximum of 3 pieces per reel. No length shorter than 50 ft.

Product Number Packaging Nominal I.D. Nominal O.D. Reinforcement Spirals Working Pressure Min. Bend Radius Weight Reels (ft.) (inches) (mm) (inches) (mm) (psi) (Mpa) (inches) (mm) (lb/ft) (Kg/m) 22554166662 500-700* 6.35 0.63 15.88 4 300 2.07 1.50 38.10 0.15 0.22 22554246662 500-700* 3/8 9.53 0.75 19.05 4 300 2.07 2.25 57.15 0.21 0.31 22554326662 500-700* 12.70 0.94 23.81 4 300 2.07 3.00 76.20 0.30 0.45 22554486662 500-700* 19.05 1.25 31.75 4 300 2.07 4.50 114.30 0.39 0.58 22554646662 300-500* 1 25.40 1.50 38.10 4 300 2.07 7.00 177.80 0.49 0.73 22554806662 300-450* 1- 31.75 1.78 45.24 4 300 2.07 8.75 222.25 0.61 0.91 22554886662 300-450* 1-3/8 34.93 1.88 47.63 4 300 2.07 9.25 234.95 0.68 1.01 22554966662 250-350* 1- 38.10 2.09 53.18 4 300 2.07 10.50 266.70 0.83 1.23

Representative image photo see BRANDING below for product stamp.
