FLEX-LOC 300 PUSH-ON

Available Black, Blue, Gray, Red, Green or Yellow Flex-Loc

TM

300 PSI is a premium hose designed specifically for use with robotic welders and industrial applications requiring an MSHA approved flame-resistant cover. It features excellent coupling retention and a superior hold created by a unique spiral angle design and aramid reinforcement that firmly grips the fitting under pressure.

Not recommended for unleaded gasoline. = Make To Order (MTO)

AIR/MULTIPURPOSE HOSES

CONSTRUCTION: Non-Conductive TUBE: Nitrile, ARPM - Class A COVER: Nitrile Blend, ARPM - Class A REINFORCEMENT: 2-Spiral Aramid Provides a Working Pressure to 300 psi More Flexible than Braid Reinforced Hose Easier to Route Assemblies Easier to Coil and Handle Less Susceptible to Premature Failure than Braided Hose if Subjected to Torque RESISTANCE BRANDING: Thermoid - Flex-Loc 300 Non-Conductive Size 300 PSI WP Made In USA MSHA 1C Month/Day/Year Time Stamp COVER COLOR: Black, Blue, Gray, Red, Green, Yellow Allows for Color Coding

Ozone Weathering Oil

Representative image photo see BRANDING below for product stamp.

Product Number Product Number Nominal I.D. Nominal O.D. Reinforcement Spirals Working Pressure Min. Bend Radius Weight 700 ft. Reels 250 ft. Reels (inches) (mm) (inches) (mm) (psi) (Mpa) (inches) (mm) (lb/ft) (Kg/m) BLACK 00318404400 00318404498 6.35 0.50 12.70 2 300 2.07 1.50 38.10 0.10 0.15 00318406400 00318406498 3/8 9.53 0.63 15.88 2 300 2.07 2.25 57.15 0.13 0.19 00318408400 00318408498 12.70 0.75 19.05 2 300 2.07 3.00 76.20 0.16 0.24 00318410400 00318410498 5/8 15.88 0.91 23.02 2 300 2.07 3.75 95.25 0.23 0.34 00318412400 00318412498 19.05 1.03 26.19 2 300 2.07 4.50 114.30 0.26 0.39 BLUE 00318504400 6.35 0.50 12.70 2 300 2.07 1.50 38.10 0.10 0.15 00318506400 3/8 9.53 0.63 15.88 2 300 2.07 2.25 57.15 0.13 0.19 00318508400 12.70 0.75 19.05 2 300 2.07 3.00 76.20 0.16 0.24 GRAY 00318604400 6.35 0.50 12.70 2 300 2.07 1.50 38.10 0.10 0.15 00318606400 3/8 9.53 0.63 15.88 2 300 2.07 2.25 57.15 0.13 0.19 00318608400 12.70 0.75 19.05 2 300 2.07 3.00 76.20 0.16 0.24 RED 00318704400 6.35 0.50 12.70 2 300 2.07 1.50 38.10 0.10 0.15 00318706400 3/8 9.53 0.63 15.88 2 300 2.07 2.25 57.15 0.13 0.19 00318708400 12.70 0.75 19.05 2 300 2.07 3.00 76.20 0.16 0.24 GREEN 00318804400 6.35 0.50 12.70 2 300 2.07 1.50 38.10 0.10 0.15 00318806400 3/8 9.53 0.63 15.88 2 300 2.07 2.25 57.15 0.13 0.19 00318808400 12.70 0.75 19.05 2 300 2.07 3.00 76.20 0.16 0.24 YELLOW 00318906400 3/8 9.53 0.63 15.88 2 300 2.07 2.25 57.15 0.13 0.19

TEMPERATURE RANGE: -30F to +180F, -34C to +82C PACKAGING: Reels 700 ft. or 250 ft. Over 80% One Piece Reels Less Scrap PRESSURELESS CURE SYSTEM Minimal Cast (Natural Curvature of the Hose) Extends the Life of the Rubber Compounds AIR MANDREL MANUFACTURING PROCESS No Internal Contamination of the Inside Diameter Due to the Lubricant Eliminates the Need for Customers to Flush the Hose MOLDED COVER PROCESS Flame Retardant
